Spesifikasi Isuzu Giga FVZ 34 L HP MIX 285 PS
ISUZU GIGA FVZ 34 L HP MIX 285 PS
Salah satu variant terbaru dari Isuzu Giga “New Product Isuzu Giga” dengan tipe Isuzu Giga FVZ 34 L HP MIX yang memiliki tenaga 285 PS dan mesin 6 silinder, penggerak mesin 6x4. Memiliki tampilan wajah baru, dengan desain baru grill dan bumper, New Isuzu Giga FVZ 34 L HP MIX paling cocok untuk penggunaan angkutan Ready Mix atau semen siap pakai di depo Batching Plant.
 |
| Isuzu Giga FVZ Molen mixer |
Berikut Spesifikasi Teknis Kendaraan dari Isuzu Giga FVZ 34 L HP MIX 285 PS
DIMENSION
Over all Length (OAL) = 7,560 mm
Over all Width (OW) = 2,485 mm
Over all Height (OH) = 2,975 mm
Wheel Base (WB1+WB2) = 3,565+1,370 mm
Front Over Hang (FOH) = 1,250 mm
Rear Over Hang (ROH) = 1,375 mm
Cabin to End (CE) = 5,460 mm
Min.Clearence (HH) = 275
Chassis width = 870x305x7.8 mm
Tread Front (AW) = 2,060 mm
Tread Rear (CW) = 1,850 mm
WEIGHT
Vehicle Mass Total = 7,270 kg
Gross Vehicle Mass (GVW) = 26,000 kg
Engine Model = 6HK1-TCN
Engine Tipe = 6-Cylinder, OHC, Direct Injection
Bore and Stroke = 115x125 mm
Piston Displacement = 7,790 cc
Max.Output = 285 PS/2400 kgm
Max.Torque = 90 kgm/1450-2400 rpm
CLUTCH DIAMETER TRANSMISSION = 380 mm
Transmission Model/Brand = ES11109DD
Transmission Operational Type = Double H
Gear Ratio Low = 12.638
Gear Ratio 1st = 8.807
Gear Ratio 2nd = 6.550
Gear Ratio 3rd = 4.768
Gear Ratio 4th = 3.548
Gear Ratio 5th = 2.482
Gear Ratio 6th = 1.846
Gear Ratio 7th = 1.344
Gear Ratio 8th = 1.000
Gear Ratio Rev. = 13.210
Final Gear Ratio = 6.143
AXLE
Capacity Rear Axle = 20,000 kg
Capacity Front Axle = 6,000 kg
Brake Type = Full Air Brake
TYRE
Front = Single, 11.00-20-16PR
Rear = Double, 11.00-20-16PR
Type = Rib Lug
Disk Wheel Size = 10STUD 20x7.50T
OTHERS
Fuel Tank Capacity = 200 ltrs
Min.Turning Radius = 7.605 m
Max.Gradeability = 45 %
Max.Speed = 83 km/h
Emission = Euro 2
Body Color = White
Cabin Suspension Type = Solid Rubber
Underguard = Yes
Warranty = 1 year/50.000 km
Alternator = 24 V-60 A
 |
